Tern NBD P8i
Details
What Makes it a P8i?
- Bosch Active Line Plus motor provides up to 50 Nm of torque and 270% support
- Bosch PowerPack 400 powers long trips, commutes, and journeys
- Shimano Nexus 8-speed internal hub
- Shimano hydraulic disc brakes for reliable stopping power-even when carrying cargo and riding fast
NBD Highlights
- Ultra-low 39 cm (15.4") standover height means gentle, low steps are all that's required to get on and go
- Ultra-low center of gravity improves balancing and maneuvering when riding with kids through parks and narrow streets
- Fits riders 147—190 cm (4'10"—6'3")
- Gaia Rack is certified to carry up to 27 kg (60 lbs) and works with many child seats
- Proven safe and reliable: frame and fork have undergone the EFBE Tri-Test to the 140 kg (309 lbs) Maximum Gross Vehicle Weight
WARNING: This product can expose you to chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Specs
| Frame | Tern NBD, 6061-AL, Patented design, EFBE Tri-Test approved: 140 kg |
|---|---|
| Fork | Tern Tarsus, 6061-AL, hydroformed, EFBE approved: 140 kg |
| Rims | Kinetix Comp, for disc |
| Hubs | Shimano Disc |
| Spokes | Stainless Steel |
| Tires | Schwalbe Big Apple, 55-406, puncture protection, Reflex |
| Bottom Bracket | Motor integrated |
| Crankset | Tern NBD custom, forged 6061-AL crankarm |
| Shifters | Shimano 8 spd. |
| Rear Derailleur | Shimano Nexus 8 |
| Cassette/Freewheel | 16T |
| Chain | KMC for eBike, EPT corrosion resistant coating |
| Brakes | Shimano, hydraulic disc |
| Brake Levers | Shimano, hydraulic disc |
| Handlebars | Tern Sweep, 6061-AL, Tern Andros adapted |
| Tape/Grips | Ergon |
| Stem | Tern Andros, adjustable, forged construction, patented technology |
| Headset | Tern Flux by FSA, cartridge bearings, Physis integrated |
| Seatpost | Tern RideEasy Suspension, 34.9 mm, Air cartridge, Preload adjustable |
| Saddle | Tern Upright by Velo |
| Pedals | MKS Platform, Tern custom design |
| Accessories & Extras | BELL: Aluminum CHAINGUARD: Tern Custom, full chain cover KICKSTAND: Ursus, rear mount LUGGAGE SOCKET: Combo Mount FRONT LIGHT: Tern Valo Direct, 190 lumens REAR LIGHT: Herrmans FENDERS: SplashGuard, stainless hardware RACK(S): Gaia Rack, 27 kg capacity, Vertical Parking FRAME LOCK: ABUS, keyed-alike with Bosch battery |
| Motor | Bosch Active Line Plus, 270% Assist, 50 Nm Torque, max speed 20 mph (US) |
| Battery | Bosch PowerPack 400 |
| Controller/Display | Bosch Intuvia, 4 mode selectable, walk assist |
| Charger | Bosch Standard Charger |
* Subject to change without notice.
Part Numbers
| Option | UPC | MPN | Store SKU |
|---|---|---|---|
| Red / One Size | 810067160018 | 12-91-02 | 210000042835 |
| Silver Blue / One Size | 812741029987 | 12-91-01 | 210000042834 |
